37kw 180kg/H Spiral Pipe Production Line
PE Spiral Pipe Production Line
We can produce large-diameter hollow spiral pipe extrusion lines from OD200 to OD3500, which are mainly used in urban drainage systems. It will be used to replace steel pipes, cement pipes and other plastic pipes in the future.
The spiral pipe production line is composed of profile pipe extruder, melt extruder, screw machine, cutting machine and some auxiliary machines. It has low investment, high output, high efficiency, stable performance, high ring stiffness, light weight per unit, good creep resistance, easy connection and economical.
The screw and barrel adopt a specially designed single-screw extruder with a unique structure, which can achieve high output, low energy consumption and good plasticization. It has a proper die structure, and two extruders provide materials to rotate the profile tube into a spiral tube.
Spiral pipe production line parameter
| NO. | Inner Diameter( mm) |
| 1 | 80 |
| 2 | 100 |
| 3 | 125 |
| 4 | 150 |
| 5 | 200 |
| Power | 380 V x 60 Hz x 3 Phase |
| Total Power | 80kw |
| Cooling Water | Recycling water. ≤20℃, ≥0.3Mpa, ～3T/h |
| Compressed air | 0.3m3/min, ＞0.5Mpa |
| Line Dimension | 18m×2.7m×2.5m |
| No. | Name & Model | Quantity |
| 1.0 | Single Screw Extruder SJ-90/30 | 1 set |
| 2.0 | Die head and Calibrator | 5 sets |
| 3.0 | Forming Machines STCJ—200 | 1 set |
| 4.0 | Haul—off Machine STLQ—200 | 1 set |
| 5.0 | Cutting Machine | 1 set |
| 6.0 | Winding Machine | 1 set |
| 7.0 | Control system | 1 set |
Key specifications/special features:
The pipe extrusion line is especially used for polyethylene made of... The polyethylene has an effective plasticizing effect on the carbon spiral pipe extrusion line. The extrusion line is especially used for polyethylene made of, which has an effective and high extrusion speed. Special separable mixing screw and standard designed spiral structure mold, reasonable passage are suitable for producing pipes with smooth inner and outer surfaces. The unique size and cooling mode can produce pipe diameters from 50mm to 200mm, and the production speed can reach 180KG/H. The diffuser of the spiral distribution style and the large flow space ensure that the melt made of has enough residence time. Excellent flexibility is suitable for co-extrusion of different types of polyethylene, and can extrude two-layer or three-layer pipes for different diameters and applications. The best spiral Cooper calibrator is equipped with a pre-cooling inlet and a powerful vacuum device to achieve high-speed extrusion.
Advantage
The PVC spiral hose extrusion production line is mainly composed of two extruders, spiral forming machines, spraying water tanks, tractors, etc. The device uses a large screw and barrel length-to-diameter ratio and has excellent plasticizing effects. The spiral forming machine adopts frequency conversion speed regulation, and the winding speed is stable. The special design of the combined machine head makes the composition of the plastic reinforcement layer and the composite layer more uniform. The pipe wall is made of hard PVC and soft PVC spirals to increase pressure. It has the characteristics of compression resistance, corrosion resistance, negative pressure resistance, bending resistance, and good fluidity. The hose is especially suitable for conveying gas, liquid, powder and granular materials.
